CPU |
- Intel Pentium IV Processor 1.6 ~ 2.2GHz OLGA
Packing, mPGA 478 Socket
- 400 MHz System Bus |
|
L2 Cache |
- 256KB |
|
Display |
- 14.1" XGA or 15.1" SXGA TFT display; Resolution:
1024x768, 1280x1024 |
|
Chipset |
- Intel 845 Chipset + ICH2 |
|
System BIOS |
- 256KB Flash EPROM
- Include System BIOS and VGA BIOS
- Plug & Play Capability
- ACPI 1.0 |
|
Memory |
- 0MB SDRAM onboard (Expandable upto 1024MB)
- 144-pin SDRAM SO-DIMM Memory Module x2 (64-bit
data bandwidth; PC-133 specification)
- 1.25" height memory size support |
|
ROM Drive |
- 24X CD-ROM or 8X DVD ROM Drive or 8x8x24 CDRW
or Combo Drive; Not removable |
|
FDD (External) |
- Support External FDD w/z USB I/F; 3.5" Format
for 720KB/1.2MB/1.44MB |
|
HDD |
- 2.5" 8.45/9.5 mm height: 6/10/12/15/20/30/40GB
- Support Ultra DMA66/100 |
|
Video |
- ATI Mobility M6-D intergrated 16MB DDR SDRAM
- Support Multi Display
- Support 4X AGP |
|
Keyboard |
- Key pitch: 19mm; Min. Key Travel: 3.0mm
- Support Windows98 system start & Application
start |
|
Buttons |
- 5X Easy Start Buttons: functions defined by
user
- 1X Mail Received Button (or function
"Recognizable Signal") |
|
Point Device |
- Glide pad with 2X buttons and 1X scroll button |
|
PCMCIA |
- Type II or Type I x 1
- CardBus support |
|
Audio System |
- Built-in sound board
- SCMS support
- AC97 I/F
- 16-bit Sampling and Playback; Full duplex
support; 3D Sound support
- Sound VR (Rotary Type)
- Built-in mono microphone and two speakers |
|
I/O Port |
- Bi-directional Parallel Port (EPP/ECP) x 1
- USB port x 2
- VGA Port x 1
- IR port x 1, complies with IrDA 1.1
- RJ-11 port x 1
- RJ-45 port x 1
- DC input x 1
- Audio out x 1 (SPIDF)
- IEEE 1394 port x1 (firewire)
- Mic-in x 1
- S-Video Out Port x 1 (NTSC/PAL) |
|
Communication |
- 10/100Base-TX LAN (Built-in)
- 56kbps V.90 MDC Modem (Built-in) |
|
Battery |
- 9-cell Li-ION Battery
- Power-on charge available
- Battery Life: 2.5hrs |
|
AC adapter |
- Universal AC adapter 60W; Input:100-240V,
50/60Hz AC |
|
Dimensions |
- 313 x 263 x 36mm |
|
Weight |
- 2.95Kg |
|
Accessories |
- TBD |
|
Architecture |
Support PC2001 Specification (Designed for
Windows 98 SE & Windows ME & Windows 2000, XP) |
